sflex groundmount box

sflex Groundmount Box opens access to areas that were previously inaccessible for PV.

Data sheet

Planning request

More impressions

Data

Application:
Outdoor
Orientation:
South and east-west installation
Connection:
Groundmount Tub
Slope:
For ground slopes up to 3°
Module type:
framed modules
Module orientation:
upright
Angle:
up to 10°
Module field size:
Min. 1 x 4 Modules / Max. 1 x 12 Modules portrait

Advantages

Quick assembly, no earthworks or concrete work required, assembly not dependent on weather conditions
Use on asphalt, soil, rocky ground, sand or landfill sites
Temporary or permanent – the tubs are foldable and suitable for both uses.
After installation, the outdoor tubs can be used immediately.
Soils remain largely untouched, as no action is required.

Components

Nothing Found

A flexible mounting solution for PV systems on various open spaces

The sflex Groundmount Box is the smart solution for ground-mounted PV projects – without the need for fixed ground anchoring. At the heart of the system are robust plastic trays that can be filled with various materials to ensure stability. Ideal for temporary or permanent installations – on almost any surface.

Modular and sturdy – even when tilted

The double-walled outdoor trays are made from 100% recycled plastic and are optimised for use on flat or slightly sloping terrain (up to 3°). Nubs and ribs on the underside reliably prevent slipping, even in windy conditions or on uneven ground. Adjustable steel adapter plates enable precise alignment of the PV modules. Quick, easy and requiring few tools.

Quick to assemble – ready for use immediately

Thanks to its material-saving design and modular construction, the Groundmount Box can be installed particularly quickly – without earthworks, without concrete, regardless of the weather. Once assembled, the system is immediately load-bearing and ready for use – this speeds up construction processes and saves resources.

Versatile – even where other systems reach their limits

Whether on asphalt surfaces, rocky ground, sandy soil or sensitive areas such as landfills, the sflex Groundmount Box is designed for a wide variety of conditions. Thanks to its ground-friendly construction without deep anchoring, the system is ideal for temporary installations, leased land, contaminated sites or terrain that is difficult to access. Even sealing membranes on landfills remain intact.
